BTM 25 Operated Double Diaphragm Pump

BYTECH BTM 25 Operated Diaphragm Pumps non metallic
Eigenschappen:
Max. capaciteit 189 l/min
Max. druk 8.6 bar
Air conn. 1/2″ BSP/NPT
Liquid conn. Combi flange DIN PN10/16
Maximum suction lift (dry) 4.9 m wc
Certificaten ATEX
Liquid conn. DN25 – 1 Ansi 150
Maximum suction lift (wet) 8.8 m wc
Maximale grootte vaste delen 3.2 mm
Max. viscositeit 10000 mPa.s
Max. temperatuur 82 °C
Materials liquids parts Polypropylene, Conductive Polypropylene, Kynar
Materials valves seats Acetal, Aluminium, Buna N, Geolast, Polypropylene, Kynar(PVDF), Hytrel, Santoprene, Stainless Steel, Viton
